Product Details:
|
| Rated Load: | 2000kg/3000kg | Tyre: | Polyurethane |
|---|---|---|---|
| Battery Volatage: | 24V | Battery Capacity: | 180Ah/280Ah |
| Maximum Travel Speed (full Load/no Load): | 5/5.5km/h | Driving Moter Power: | 1.6/2.5kw |
| Minimum Turning Radius: | 1200mm/1290mm | Drive Type: | Stand Type |
| Highlight: | 2 Ton baggage towing tractor,Electric baggage towing tractor,3 Ton electric tow tractor |
||
| Model | QD20 | QD30 | ||
| Features | Powe type | Battery | ||
| Drive type | Stand type | Stand type | ||
| Rated load | kg | 2000 | 3000 | |
| Drawbar height | mm | 186 | 310 | |
| Drawbar pull (60 minutes) | N | 700 | 1000 | |
| Drawbar pull (5 minutes) | N | 2100 | 3000 | |
| Weight | Weight (with battery) | kg | 540 | 720 |
| Driving axle load | kg | 340 | 440 | |
| Bearing axle load | kg | 200 | 280 | |
| Tires | Tyre(Rubber,High elastomer,Polyurethane,Pneumatic) | Polyurethane | ||
| Driving tyre | mm | Φ230×75 | ||
| Rear tyre | mm | Φ178×73 | ||
| tyre quantity driving/Rear | 1x /2 | |||
| Tread(Rear tyre) | mm | 510 | 640 | |
| Dimensions | Overall length | mm | 1350 | 1413 |
| Overall width | mm | 660 | 745 | |
| Overall height | mm | 1500 | ||
| Minimum ground clearance | mm | 40 | ||
| Wheelbase | mm | 980 | 1050 | |
| Minimum right angle aisle width | mm | 1400 | 1490 | |
| Minimum turning radius | mm | 1200 | 1290 | |
| Performance | Maximum travel speed (full load/no load) | km/h | 5/5.5 | |
| Maximum gradeability (full load/no load) | % | 3/5.0 | ||
| Service brake | Electromagnetic brake | |||
| Power | Driving moter power | kw | 1.6 | 2.5 |
| Battery volatage/capacity | V/Ah | 24/180 | 24/280 | |
| Battery weight | kg | 146 | 250 | |
| Battery size | mm | 570×262×600 | 700×272×600 | |
Features
1.The vehicle uses Cortez's latest controllers and gauges, which display hours, power levels and a fault code.
2.The steering mode is electric steering, and the steering operation is more comfortable.
